NTE10/3 Professional Audio Transformer can be customized

Description

1、Core Specifications and Functions
Basic Parameters
Turn ratio: 1:3:10
Impedance ratio: 200Ω : 1.8kΩ (can also achieve 200Ω:20kΩ/50kΩ matching)
Maximum input level: approximately -7dBu (1% THD @ 50Hz)
Structure: Comes with 5 colored leads (red / blue / black / yellow / white), facilitating wiring

2、Main Applications
Impedance matching: Used for converting balanced / unbalanced signals, or for adapting between devices with different impedances (such as converting low-res microphone signals to high-res line signals)
Signal isolation: Achieves electrical isolation of audio signals through transformers, eliminating ground loop noise (current hum)
Level conversion / splitting: Used in custom audio adapters, splitters, or passive signal distributors, commonly found in Neutrik NM series adapter modules

3、Usage Instructions and Precautions
When wiring, refer to the official pin definitions: red / white for the primary side, yellow / black / blue for the secondary side. Different wiring methods can achieve different impedance ratios.
This is an inductive component, no power supply is required, but attention should be paid to signal level matching to avoid overload distortion.
Typical application scenarios: professional stage audio equipment, recording studio signal conversion, custom audio cables / adapters, etc.
